Advantages

Specially developed design provides targeted cooling of high-density racks, regardless of their manufacturer.

Horizontal air flow
The cold air enters the rack in the shortest way, mixing a little with the heated air, this increases the cooling efficiency.

Controller C7000
Permanent monitoring and precise control of all components inside and outside the air conditioner. Six temperature sensors for controlled closed-loop cooling.

Up to five EC fans
EC fans operate independently of each other. The infinitely variable speed control allows flexible adaptation to changes in temperature conditions.

EC compressor
Infinitely variable control ensures optimum cooling performance, inverter technology allows not to increase the starting current.

Сonfiguration variability
Choice of four cooling systems and six nominal sizes. Installed with and without a raised floor.

Use for modernization
The compact size and universal design allows the system to be used for the modernization of air conditioning systems in existing premises.

Specifications

• Four cooling systems: AS — compressor, CW — liquid, GS — compressor and plate condenser, GES — secondary free cooling
• Front and rear service access
• RS485 port for connection to building management systems
• Pleated plate filter G4 class in metal frame
• Powder-coated outer frame, hinged front and rear panels
• Cooling water and refrigerant pipes are supplied from above and below
• The rack and air conditioner are not connected by cables and pipes, that increases the layout possibilities
• Possibility to install a humidifier and a heater
